UST Projector Screens Explained: Why Your Laser TV Needs a Special Screen
If you own a Hisense TriChroma, Samsung The Premiere, AWOL Vision, or any other UST laser TV, a regular matte white or ALR screen will produce a blurry, uneven, low-contrast image. This isn't a flaw in your projector — it's a physics problem that requires a UST-specific optical surface to solve.
TrueThrow Fresnel UST Screen — 4K Image Quality
Real-world image quality with a UST laser projector on TrueThrow Fresnel ALR.
TrueThrow Fresnel UST Screen — Daylight Performance
How the Fresnel ALR handles ceiling light and daylight — the key advantage over a standard screen.
Why UST Projectors Are Different
A standard projector sits 10–15 feet from the screen and projects at a nearly horizontal angle. Every screen on the market is designed for this geometry.
A UST (ultra-short throw) projector sits 15–50 cm from the screen base and fires light steeply upward at an angle of 50–70 degrees from horizontal. This steep angle creates two problems with any flat screen surface:
- Diffusion blur: The screen's matte white coating scatters this steep-angle light in all directions, including sideways and back into itself — creating a blurry, veiled image
- Uneven brightness: The bottom of the image (closest to the projector) appears brighter than the top, because the light path length increases rapidly with height
How UST Screens Solve This
UST screens use a Fresnel lens structure or lenticular (micro-lens array) structure etched or laminated onto the screen surface. This directional optical layer does two things:
- Collects steep-angle light from the projector and redirects it straight forward toward the viewer — solving the diffusion blur
- Rejects ambient light from other angles (ceiling, windows) — because that light doesn't arrive at the correct angle to pass through the Fresnel structure
The result: a sharp, bright, high-contrast image with simultaneous ambient light rejection. This is why a proper UST screen can outperform a matte white screen even in the same room.
Types of UST Screens — Which One?
Fresnel ALR UST Screen
The entry-level and most popular UST screen type. Uses a Fresnel lens array with an ALR backing. Gain 1.40, 88% reflectivity, 130° viewing angle. Best for: all UST projectors in rooms with moderate ambient light. TrueThrow's Fresnel ALR starts at $272 for 80".
CBSP Carbon Black UST Screen
A Fresnel structure with a carbon-black absorptive backing layer. The carbon black backing absorbs inter-reflection between screen layers, producing deeper blacks than standard Fresnel. Gain 0.72, 96% reflectivity, 160° viewing angle. Best for: maximum contrast in brighter rooms. TrueThrow's CBSP Carbon Black starts at $320.
PET Crystal BSP UST Screen
Uses a PET (polyethylene terephthalate) substrate that allows partial acoustic transparency — sound can pass through. Gain 0.60, 95% reflectivity, 160° viewing angle. Best for: setups with a centre speaker behind the screen. TrueThrow's PET Crystal BSP is this type.
HBSP Premium Hard-Coat UST Screen
The flagship UST surface — a Fresnel structure with a hard optical coating that resists micro-warping and surface marring over time. Gain 0.60, 96% reflectivity, 160° viewing angle. Best for: permanent installations where longevity and surface durability are priorities. HBSP Premium.
Compatible UST Laser TVs and Projectors
All TrueThrow UST screens are compatible with:
- Hisense: PX1-PRO / PX2-PRO TriChroma Laser TV, L9G, 100L5F
- Samsung: The Premiere LSP7T / LSP9T
- AWOL Vision: LTV-2500 / LTV-3000 Ultra / LTV-3500 Pro
- LG: HU85LA / HU915QE CineBeam UST
- Epson: LS800 / LS805B
- XGIMI: Aura 4K / Aura 2
- BenQ: V7050i / V6050 / V5000i
- Optoma: CinemaX P2 / D2
- ViewSonic: X1000-4K / X2000B-4K
UST Screen Sizing
UST projectors are typically rated for specific screen sizes — your projector manual will specify the compatible screen size range. Most Hisense, Samsung, and AWOL models are designed for 80"–120" screens. The projector-to-screen distance is very short (15–50 cm) and fixed by the projector design — you can't adjust the throw distance the way you can with a standard projector.
Installation Notes
UST screens mount exactly like fixed frame screens — wall-mounted on a rigid aluminium frame. The screen material is rigid (not fabric) and requires no tensioning. The projector sits on a stand or console table directly below the screen. No ceiling mount, no complex alignment. Most TrueThrow UST screen installations take 30–45 minutes.
All TrueThrow UST screens ship free. Browse the full UST screen collection or use the Screen Guide to find the right surface for your specific laser TV.
Frequently Asked Questions
Do you need a special screen for a UST projector?
Yes. UST projectors fire light at a steep upward angle from very close range. A standard matte white screen scatters this light, causing blur, uneven brightness, and poor contrast. A UST-specific Fresnel or lenticular screen collects the steep-angle light correctly and rejects ambient ceiling light simultaneously. You cannot get good results from a UST projector on a regular screen.
What is the best screen for Hisense TriChroma laser TV?
TrueThrow's Fresnel ALR UST Screen is the recommended match for Hisense TriChroma. For the best contrast in a bright room, the CBSP Carbon Black UST delivers deeper blacks. Both ship free and are verified compatible with the Hisense PX1-PRO and PX2-PRO.
Can I use a Fresnel screen with a regular projector?
No. A Fresnel UST screen is designed specifically for the steep projection angle of UST projectors. A standard projector projecting at a near-horizontal angle will produce a dim, incorrectly focused image on a Fresnel screen. For standard projectors, use a matte white or ALR fixed frame screen.
What screen does Samsung The Premiere use?
Samsung The Premiere LSP7T and LSP9T require a UST-specific screen. TrueThrow's Fresnel ALR and CBSP Carbon Black UST screens are verified compatible. Samsung sells their own "The Screen" accessory, but TrueThrow UST screens deliver equivalent optical performance at a significantly lower price point, with free shipping.
Are UST projector screens available with free shipping?
Yes. TrueThrow ships all UST projector screens free to every region — Ontario, BC, Alberta, Quebec, and all other provinces. No brokerage, no customs fees. Delivery in 5–7 business days. UST screens start at $272 for the 80" Fresnel ALR.
